Description

Experience 3D Spacious Surround Sound at Home

Make your viewing or gaming experience more immersive than ever before with the winning combination of JBL Multibeam™ technology and Virtual Dolby Atmos®. Feel the sound all around as you're thrown into the action with deep bass performance without the need for an extra subwoofer. It features Chromecast built-in™, AirPlay and Alexa Multi-Room Music (MRM) for incredibly easy music streaming and multi-room possibilities. Bluetooth lets you enjoy music from your smartphone or tablet too. The sleek design of the JBL Bar 5.0 MultiBeam, with its grille pattern and metallic finishing, fits any home decor. It's compact and simple to use, can be controlled using your existing TV remote or by using the included intuitively designed remote control.

General Specifications

Total speaker power output: 250 W

Soundbar output power (Max. @THD 1%): 5 x 50 W

Transducer: 5 x 48mm x 80mm racetrack drivers + 4 x  3 inches(75mm) Passive Radiators

Power supply: 100 - 240V AC, ~ 50/60Hz

Audio Specifications

Max SPL: 92 dBA

Frequency Response: 50Hz - 20KHz

1 Optical, Bluetooth, Chromecast, AirPlay 2, Alexa MRM, USB

MP3 Codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3 (USA only), Dolby Atmos, PCM

Dimensions

Dimensions (W x H x D): 709x 58x 101mm, 27.9x 2.3x 3.9"

Weight

13.47 kg

Control and Connection Specifications

Type A, USB rating : 5V DC, 0.5A

USB Port: (*USB playback is available in US version. For other versions, USB is for Service only.)

Bluetooth® version: 4.2

Bluetooth® profile: A2DP 1.2, AVRCP 1.5

Bluetooth® transmitter frequency range: 2400 MHz – 2483.5 MHz

Bluetooth® transmitter power: <10 dBm (EIRP)

Wi-Fi network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range: 2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)

2.4G Wi-Fi transmitter power: <20dBm

5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz

5G Wi-Fi transmitter power: <23dBm (EIRP)

What's in The Box?

1x Soundbar

Remote control with 2 x batteries

Power cords (up to 8pcs depending on region SKUs)

1x HDMI cable

2 x L-shape Wall-mount bracket with screws

Quick start guide

Warranty card

Safety sheet
